P. 6
Programming of Toilet Flush Control
PROGRAMMING
3. Push the EMPTY ONLY button. Flush mode
NOTE: Flush control is set at factory to work will switch from Sequential to Continuous or vice
in most installations. Use following instructions versa. The Holding Tank Full LED will flash THREE
to re-program if adjustment on water levels and times indication you have left program mode.
timings are needed.
Programming your Smart Toilet Control:
The Raritan Smart Toilet Control offers two The Raritan Smart Toilet Control is factory set to
different flush modes to choose from: work in most installations and no programming is
required. The following instructions can be used to
Sequential Flush: In this mode, the toilet will modify timings if desired:
add water and discharge waste separately. This
fill/empty cycle will repeat three times during the All flush cycles have an initial fill time (T1),
Discharge/Empty time (T2) and water retention fill
NORMAL FLUSH cycle. At the end of this time (T3).
sequence cycle, a short pause will be followed by
a final fill to leave water remaining in the bowl. Factory default settings for the NORMAL
This mode is designed to provide the most efficient FLUSH are as follows:
flush possible while using the least amount of Sequential mode: T1= 3 sec, T2= 3 sec, T3= 2 sec
water. It keeps the discharge pump flooded while Continuous mode: T1= 3 sec, T2= 12 sec, T3= 2 sec
providing powerful suction to remove waste from Step 1 - Entering program mode:
the bowl. Hold the WATER ONLY and
NOTE: All toilets as shipped from factory are EMPTY ONLY buttons down together for 3
set to the Sequential mode. seconds. The Holding Tank Full LED will flash
Continuous Flush: In this mode, the toilet will THREE times indicating you have entered program
add water to wet the bowl first and then follow with mode - release both button.
the inlet and discharge motors flushing together Setting T1 initial fill time:
for the remainder of the cycle. At the end of this After entering program mode (Step 1 above) push
continuous cycle, a short pause will be followed the NORMAL FLUSH button once. Continue
by a final fill to leave water in the bowl. to press the NORMAL FLUSH button equiva-
This mode may be more suitable for installations lent to the number seconds you wish water to enter
in which a continuous flow of water is desired and the bowl: (one push= 1 second, 2 pushes= 2 sec-
water use is not as great a concern. onds, etc.). The Tank LED will flash after each valid
key push. The maximum inlet time is 20 seconds.
When finished, push the EMPTY ONLY button
Changing flush mode from Sequential to to store this value and exit. The Holding Tank Full
Continuous and vise versa: LED will flash THREE times indicating you have
left program mode.
1. Hold the WATER ONLY and EMPTY Setting T2 Discharge Pump Time:
ONLY buttons down together for three After entering program mode (Step 1 above) push
seconds. The Holding Tank Full LED will flash the EMPTY ONLY button once. Continue to
THREE times indicating you have entered pro- press EMPTY ONLY button equivalent to the
gram mode. number of seconds you wish water to exit the bowl:
2. Push the WATER SAVER button (one push= 1 second, 2 pushes= 2 seconds, etc.).
once.
